SECURENET CAT6 U/UTP Cable for Indoor use 305 mtrs- Red
Attribute | Details |
|---|---|
Brand | SECURENET |
Cable Category | CAT6 U/UTP (Unshielded Twisted Pair) |
Cable Type | Indoor LAN Cable |
Cable Colour | Red |
Conductor Diameter | 0.57 mm (23 AWG) (Typically) |
Conductor Material | Bare Copper (if not CCA) |
Conductor Stranding | Solid |
Conductor Count | 8 Conductors (4 twisted pairs) |
Conductor Insulation Material | Polyethylene |
Cable Jacket Material | Fire Retardant PVC (FR PVC) |
Internal Cross Separator | Yes |
Length of Cable Bundle | 305 meters (1000 feet) |
Bandwidth Frequency | 250 MHz |
Data Transmission Rate | Up to 1000 Mbps (Gigabit Ethernet) |
Supported Applications | 10BASE-T, 100BASE-TX, 1000BASE-T, PoE, PoE+, 155/622 Mbps ATM, ISDN, Voice |
Maximum DC Resistance | ≤ 100 Ohm/Km |
Sequential Meter Marking | Yes (Printed every meter) |
Operating Temperature Range | -20°C to +60°C |
Storage Temperature Range | -20°C to +60°C |
Installation Environment | Indoor Use Only |
UL Marking on Cable | Yes |
General
- Types Of CablesUTP Cables
- UTP Cables TypesCat 6
- Outer MaterialCopper
- Product ColourRed
Size
- Item Length305 m
